Force-Displacement (Torque-Angle) Graphing Software

Force Recorder Professional

  1. Force Measurement IMADA
  3. Software
  4. Force Recorder Professional

Description Add to favorites

Force Recorder Professional Graphing Image Force Recorder Professional Graphing Image

Force Recorder Professional CD Force Recorder Professional CD

Force Recorder Professional Graphing Image

Force Recorder Professional CD

Hi Res Graph

Overlaying Graphs

Multi Function

Force-Disp Graph

Force Recorder Professional is force-displacement (torque-angle) graphing software for ZTA/eZT/FA Plus2/HTGA//DTXA series digital force gauges. It graphs measurement accurately and precisely even for small force changes at high sampling rate (2000Hz).


  • Allows force-displacement graphing connecting with ZTA/eZT/FA Plus2 series force gauge, torque-angle graphing connecting with HTGA/DTXA series torque gauges* A length scale, angle meter or a test stand with -FA option is necessary
  • Enables accurate graphing with high sampling rate of max. 2000Hz, adjustable to suit the measurement purpose; capturing rapid transitions precisely at high sampling rate or monitoring moderate changes for a long recording time at slower rate
  • Equips various editing functions such as trigger function for automatic recording and graphing, graph overlaying, border line, and capture functions
  • Prints out a report with graph, statistics including Max/Min/Ave values, and comments
  • Ideal for material characteristic evaluation and tactile testing by force-displacement graphing *Force-displacement Measurement Unit FSA series and torque-angle measurement unit TAA series also available

Relevant Information and Materials

User Guide Videos


Install the Software


Change Graph Display Setting, Change/Save the Setting of Force Gauge


Set up Trigger Function/Use Graph Analyzing Tools

Data Record

Data Graphing

Data Record

Data Export/Print/Copy/Paste

Data Record

Force-Displacement Data Graphing
