Description

Construction / Furniture

As the industry covers diversified situations, so does the force measurement. Such examples include closing force evaluation for inspection of fire doors and revolving doors, 3-point bending test of timber using for buildings, tactile test of earthquake-proof mat, and sliding force measurement of drawers.
