Precision Model Mechanical Force Gauge

PSM series

PSM series

Description Relevant Information and Materials Relevant Products User Guide Videos
CONTACT
  1. Force Measurement IMADA
  2. PRODUCTS
  3. Mechanical Force Gauges (Push Pull Gauges)
  4. PSM series

Description Add to favorites

PSM-200N PSM-200N

PSM Series Standard Set PSM Series Standard Set

PSM-200N

PSM Series Standard Set

No Ext Power

Robust

Hi Precision

Hi Resolution

Precision type mechanical force gauge has capacity of 500N, and is with high accuracy of ±0.1% and fine memory equalization. Ideal for precise measurements. They support compression and tension, and are also equipped with a stop mechanism that stops the needle at the peak value.

Feature

  • Easy handling with less risk of malfunctions or glitches caused by external circumstances such as noise or static electricity due to the rugged mechanical construction
  • The highest precision model with high resolution scale which is ideal for high precision test
  • Measures both compression and tension force
  • Captures peak value easily using switchable peak hold function
  • Assists accurate measurement with tare ring to adjust zero

User Guide Videos

Setting

Zero Adjustments

Setting

Peak Value Detection

Mounting

Optional Handle Attachment for Accurate Measuring

Measurement

Tension Tests

Measurement

Compression Tests

Troubleshooting

Handling Precautions for Avoiding Over-Load
