High Capacity Model Mechanical Force Gauge

PSH series

  1. Force Measurement IMADA
  2. PRODUCTS
  3. Mechanical Force Gauges (Push Pull Gauges)
  4. PSH series

Description Add to favorites

PSH-1000N PSH-1000N

PSH Series Standard Set PSH Series Standard Set

PSH-1000N

PSH Series Standard Set

No Ext Power

Robust

Hi Precision

Hi Force

High-capacity type mechanical force gauge has capacity of 3000N. They support compression and tension, and equipped with a stop needle mechanism that stops the needle at the peak value.

Feature

  • Easy handling with less risk of malfunctions or glitches caused by external circumstances such as noise or static electricity due to the rugged mechanical construction
  • High precision and capacity model which is ideal for precise test
  • Measures both compression and tension force
  • Captures peak value easily using switchable peak hold function
  • Assists accurate measurement with tare ring to adjust zero

User Guide Videos

Setting

Zero Adjustments

Setting

Peak Value Detection

Measurement

Tension Tests

Measurement

Compression Tests

Troubleshooting

Handling Precautions for Avoiding Over-Load
