Advanced Type Vertical Motorized Test Stand

EMX2 series

Description Relevant Information and Materials Relevant Products User Guide Videos Optional Module Introduction

CONTACT

Description

EMX2-500N

EMX2-500N+ZTS-50N

Lo-Mid Force

Hi Rigidity

Wide Speed Range

Ext I/O

Contact Detection

Digital Speed Ctrl

Multi Function

Displacement OPT

A motorized test stand designed to build a compact tabletop force testing system. Used with force gauges such as ZTA series, it enables highly repeatable testing under controlled conditions. Motion can be controlled by force or displacement values, allowing test procedures that are difficult to perform consistently by manual operation. Models equipped with a linear scale can acquire force and displacement data simultaneously. The system is suitable for compression and tensile testing applications, including material characterization and operability evaluation. Up to 10 test conditions can be stored in memory for quick setup and efficient switching between test methods. Note: Some functions require a compatible force gauge and connection cable.

Feature

A motorized test stand for highly repeatable tabletop testing. Combined with various attachments, it supports a wide range of sample evaluations.
Auto Test Mode automatically stops or reverses motion based on force values or displacement, enabling testing under conditions that are difficult to achieve manually.
Up to 10 Auto Test Mode settings can be stored in memory for quick setup and easy switching between test conditions.
Included software allows test conditions to be created and edited from a PC using templates, simplifying setup and switching between test conditions.
Models equipped with a built-in linear scale (-FA) can simultaneously measure force and displacement. Their highly rigid structure (maximum deflection: 0.25 mm) enables more precise force-displacement testing.

Relevant Information and Materials

EMX2 series Specifications Test Stand Comparison Table CS Test Preset Builder Specification

Relevant Products

Standard Model Digital Force Gauge

ZTS series

High Functionality Model Digital Force Gauge

ZTA series

Force-displacement Measurement Unit

FSA series

Force-Time (Torque-Time) Graphing Software

Force Recorder Standard

Force-Displacement (Torque-Angle) Graphing Software

Force Recorder Professional

Downloadable Force-Time (Torque-Time) Graphing Software

Force Recorder Next Standard

Downloadable Force-Displacement (Torque-Angle) Graphing Software

Force Recorder Next Professional

External Signals I/O Cable (MX3-CN/EMX2)

CB-716

Displacement Cable (MX2-FA/MH2-FA/EMX-FA with firmware version 2.0 or later - ZT connection)

CB-718
