Plug-in for Force Recorder Next Series (For Specified Peak Extraction)

Multi-Peak Extraction Function

Multi-Peak Extraction Function

Description Relevant Information and Materials Relevant Products
CONTACT
  1. Force Measurement IMADA
  2. PRODUCTS
  3. Additional Chargeable Function for Software
  4. Multi-Peak Extraction Function

Description Add to favorites

Multi-Peak Extraction Function Display Image Multi-Peak Extraction Function Display Image

Plug-in software

Downloadable Product

Multi-Peak Extraction

Multi-Peak Extraction Function is a plug-in for the Force Recorder next Series. This function allows users to specify peak points within the measurement results and extract and display their corresponding force values. Up to five points can be designated. In addition to these force values, it automatically displays the force values of the first and last peaks, the total number of peaks detected across all measurement data, and comparisons such as the ratio between the minimum and maximum peak values. *Download Card Basic is required.

Feature

  • Extract force values from any selected peaks in the measurement graph after applying repeated loads to the sample during durability tests.
  • Analyze peak information to assess the degree of sample fatigue.
  • Easily identify critical points such as the timing of sample failure by analyzing peak data.
  • Export specified peak information using dedicated report templates or in CSV format.

Relevant Information and Materials

Additional Downloadable Chargeable Functions for Force Recorder Next Series Additional Functions and Various Services for Next Series Download Card Specification
